Name: TrafficLight_Control_POINT

Display Field: GEODBID

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: OBJECTID: System-generated unique identifier for each record within the feature classGEODBID: Three-digit code that assigns editing responsibility to a community in the GIS ConsortiumFEATUREID: GIS-Consortium-generated unique identifier for each record within the feature class. All FEATUREIDs start with the GEODBID of the community that owns the record.DATECREATED: Date/time stamp from the moment the GIS record was created DATEMODIFIED: Date/time stamp from the last moment the GIS record was changed SOURCE: Organization that provided the data. The GIS Consortium standard is to preface the source with the three-letter municipal code of the community providing the data, followed by a dash. Example: VGV-Public WorksSOURCETYPE: Accuracy context for the recordPRODUCTIONNOTES: Technical notes from GIS personnelREPLICAFILTER: Code used to filter data for the creation of custom geodatabasesTRAFFICLIGHTCONTROLID: Unique identifier of the traffic light controllerCONTRACTOR: Organization or individual hired for contractCONTACTINFO: Contact information of the contractorOWNERSHIP: Organization with jurisdiction over the real-world feature represented in the feature classCONTROLLERMODEL: Model of the traffic light controllerCONTROLLERBRAND: Brand of the of the traffic light controllerFID_SUPPORTSTRUCTURE_POINT: Unique identifier that can be joined to the FEATUREID field of the StreetUtility_Support_POINTto provide a link between the traffic light control and the support structure FID_STREETINTERSECTION_POINT: Unique identifier that can be joined to the FEATUREID field of the StreetIntersection_POINT to provide a link between the traffic light control and the street intersection.GlobalID: System-generated unique identifier for each record that is required in replicated geodatabasesSUBTYPE: Additional designation of the feature e.g. pedestrian button, emergency vehicle preemption (EVP), control boxMAINTENANCE: Organization responsible for the care of the real-world feature represented in the feature classINSTALLDATE: Date that the control was installedSHAPE: System-generated geometry type of the featureGID_SUPPORTSTRUCTURE_POINT: Unique identifier that can be joined to the GlobalID field of the StreetUtility_Support_POINTto provide a link between the traffic light control and the support structure GID_STREETINTERSECTION_POINT: Unique identifier that can be joined to the GlobalID field of the StreetIntersection_POINT to provide a link between the traffic light control and the street intersection.LIFECYCLESTATUS: Current state of the real-world featureWEBLINK: URL for a website related to the record

Copyright Text: Created by the GIS Consortium's members with ongoing updates.

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 10000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 973041.9162500016
YMin: 1829318.0515
XMax: 1153631.4365000017
YMax: 2044799.625
Spatial Reference: 102671  (3435)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: SUBTYPE

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• GEODBID ( type: esriFieldTypeString, alias: GEODBID, length: 3 , Coded Values: [001: CHP] , [003: CPR] , [005: CDP] , ...83 more... )
• FEATUREID ( type: esriFieldTypeString, alias: FEATUREID, length: 15 )
• DATECREATED ( type: esriFieldTypeDate, alias: DATECREATED, length: 8 )
• DATEMODIFIED ( type: esriFieldTypeDate, alias: DATEMODIFIED, length: 8 )
• SOURCE ( type: esriFieldTypeString, alias: SOURCE, length: 20 )
• SOURCETYPE ( type: esriFieldTypeString, alias: SOURCETYPE, length: 20 , Coded Values: [ASBUILT: As-built] , [DATABASE: Database] , [ESTIMATED: Estimated] , ...12 more... )
• PRODUCTIONNOTES ( type: esriFieldTypeString, alias: PRODUCTIONNOTES, length: 100 )
• REPLICAFILTER ( type: esriFieldTypeString, alias: REPLICAFILTER, length: 255 )
• TRAFFICLIGHTCONTROLID ( type: esriFieldTypeString, alias: TRAFFICLIGHTID, length: 20 )
• CONTRACTOR ( type: esriFieldTypeString, alias: CONTRACTOR, length: 100 )
• CONTACTINFO ( type: esriFieldTypeString, alias: CONTACTINFO, length: 100 )
• OWNERSHIP ( type: esriFieldTypeString, alias: OWNERSHIP, length: 50 , Coded Values: [ADT: Addison Township] , [ATP: Antioch Township] , [AIL: Aqua Illinois] , ...212 more... )
• CONTROLLERMODEL ( type: esriFieldTypeString, alias: CONTROLLERMODEL, length: 50 )
• CONTROLLERBRAND ( type: esriFieldTypeString, alias: PREEMPTIONDEVICEBRAND, length: 255 )
• FID_SUPPORTSTRUCTURE_POINT ( type: esriFieldTypeString, alias: FID_SUPPORTSTRUCTURE_POINT, length: 15 )
• FID_STREETINTERSECTION_POINT ( type: esriFieldTypeString, alias: FID_STREETINTERSECTION_POINT, length: 15 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• SUBTYPE ( type: esriFieldTypeSmallInteger, alias: SUBTYPE )
• MAINTENANCE ( type: esriFieldTypeString, alias: MAINTENANCE, length: 100 , Coded Values: [ADT: Addison Township] , [ATP: Antioch Township] , [AIL: Aqua Illinois] , ...212 more... )
• CREATEDBY ( type: esriFieldTypeString, alias: CREATEDBY, length: 100 )
• MODIFIEDBY ( type: esriFieldTypeString, alias: MODIFIEDBY, length: 100 )
• GID_SUPPORTSTRUCTURE_POINT ( type: esriFieldTypeGUID, alias: GID_SUPPORTSTRUCTURE_POINT, length: 38 )
• GID_STREETINTERSECTION_POINT ( type: esriFieldTypeGUID, alias: GID_STREETINTERSECTION_POINT, length: 38 )
• OWNERSHIPDESCRIPTION ( type: esriFieldTypeString, alias: OWNERSHIPDESCRIPTION, length: 50 )
• INSTALLDATE ( type: esriFieldTypeDate, alias: INSTALLDATE, length: 8 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• LIFECYCLESTATUS ( type: esriFieldTypeString, alias: LIFECYCLESTATUS, length: 10 , Coded Values: [ABANDONED: Abandoned] , [ACTIVE: Active] , [PROPOSED: Proposed] , ...2 more... )
• WEBLINK ( type: esriFieldTypeString, alias: WEBLINK, length: 255 )
• LOCATIONDESCRIPTION ( type: esriFieldTypeString, alias: LOCATIONDESCRIPTION, length: 255 )

Types:

ID: 0
Name: Unknown
Domains:
• GEODBID:
  Inherited
• SOURCETYPE:
  Inherited
• OWNERSHIP:
  Inherited
• MAINTENANCE:
  Inherited

---

ID: 1
Name: Control Box
Domains:
• GEODBID:
  Inherited
• SOURCETYPE:
  Inherited
• OWNERSHIP:
  Inherited
• MAINTENANCE:
  Inherited

---

ID: 2
Name: Pedestrian Button
Domains:
• GEODBID:
  Inherited
• SOURCETYPE:
  Inherited
• OWNERSHIP:
  Inherited
• MAINTENANCE:
  Inherited

---

ID: 3
Name: Emergency Vehicle Preemption (EVP)
Domains:
• GEODBID:
  Inherited
• SOURCETYPE:
  Inherited
• OWNERSHIP:
  Inherited
• MAINTENANCE:
  Inherited

---

ID: 4
Name: Red Light Camera
Domains:
• GEODBID:
  Inherited
• SOURCETYPE:
  Inherited
• OWNERSHIP:
  Inherited
• MAINTENANCE:
  Inherited

---

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
