Layer: Transportation_LINE (ID: 93)

Name: Transportation_LINE

Display Field: FID_STREETNAME_TABLE

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: OBJECTID: System-generated unique identifier for each record within the feature classGEODBID: Three-digit code that assigns editing responsibility to a community in the GIS ConsortiumFEATUREID: GIS-Consortium-generated unique identifier for each record within the feature class. All FEATUREIDs start with the GEODBID of the community that owns the record.DATECREATED: Date/time stamp from the moment the GIS record was created DATEMODIFIED: Date/time stamp from the last moment the GIS record was changed SOURCE: Organization that provided the data. The GIS Consortium standard is to preface the source with the three-letter municipal code of the community providing the data, followed by a dash. Example: VGV-Public WorksSOURCETYPE: Accuracy context for the recordPRODUCTIONNOTES: Technical notes from GIS personnelREPLICAFILTER: Code used to filter data for the creation of custom geodatabasesFID_STREETNAME_TABLE: Unique identifier that can be joined to the STREETNAME_TABLE to provide current street names.TRACKTYPE: Ranking of the path as primary, secondary, or tertiary. Used for cartographic symbologyOWNERSHIP: Organization with jurisdiction over the real-world feature represented in the feature class/tableMAINTENANCE: Organization responsible for the care of the real-world feature represented in the feature class/tableFID_ENTITYNAME_TABLE: Unique identifier that can be joined to the ENTITYNAME_TABLE to provide the names of important places associated with the street segment.TYPE: Type of transportation. Includes the following: 0 – UNKNOWN1 – ROAD2 – RAILROAD3 – PATH4 – SIDEWALK5 - FERRYCLASS: Classification of the transportation road type. Includes the following:1 – Interstate – A main road intended for high-speed travel connecting two or more states2 – Major Road (Arterial) – A moderate- or high-capacity road that is immediately below the interstate level of service. Accommodates through traffic. Much like a biological artery, an arterial road carries a large volume of traffic between areas in urban centers.3 – Secondary Road (Collector) – A low- or moderate-capacity road that is below the interstate and major road levels of service. Secondary roads tend to lead traffic from local roads or sections of neighborhoods to activity areas with communities, major roads, or occasionally directly to expressways or freeways.4 – Local Roads – A road intended only for the traffic of local residents and visitors. "Frontage Road" and "Service Road" are under this classification.5 – Alley – A narrow road that runs between or behind buildings. Usually located along the back lot lines of properties. DESIGNATION: The federal- or state-assigned number for the roadSYSTEM: System of the road type. Includes the following: 0 – UNKNOWN 1 – INTERSTATE HIGHWAY 2 – US HIGHWAY 3 – STATE HIGHWAY 4 – COUNTY HIGHWAY 5 – LOCAL ROADCLASSIFICATIONCODE: The federal aid code assigned to the road segment, which indicates the source of funding for road maintenance. The letter codes listed below will be followed by a dash and a number designation. Example: FAU-1291 is Federal Aid Urban code number 1291.FAI – Federal Aid Interstate FAP – Federal Aid PrimaryFAS – Federal Aid SecondaryFAU – Federal Aid Urban CH – County HighwaySBI – State Bond IssueHB – House BillSB – State Bill TR – Township Road MUN – Municipal OR – Other Roads SUBCLASS: This field is used to store Census Feature Class Codes (CFCC), a classification system used by the US Census Bureau in the TIGER database to code a detailed description of a physical object’s characteristics. There are 222 CFCC codes, 54 of which start with A and are applicable to roads. See this websitefor a complete list of CFCC codes.LANES: Number of lanes on the roadSURFACETYPE: Material used on the surface of the roadSTATEDOTCLASS: This field is designed to hold I-DOT classifications. It can also serve as a temporary holding place for CMAP classifications as needed. In a future schema update, a new field will be added to hold CMAP classification codes. I-DOT ClassificationIL1 – Interstate IL2 – Other Freeways and Expressways IL3 – Other Principal Arterial IL4 – Minor Arterial IL5 – Major Collector IL6 – Minor Collector IL7 - LocalCMAP Classification10 – Interstate (PAS) 20 – Freeway and Expressway (Urban Only) (PAS) 30 – Other Principal Arterial (PAS) 40 – Minor Arterial (Non-Urban) 50 – Major Collector (Non-Urban) 55 – Minor Collector (Non-Urban) 60 – Local Road or Street (Non-Urban) 70 – Minor Arterial (Urban) 80 – Collector (Urban) 90 – Local Road or Street (Urban) SPEEDLIMIT: The speed limit on that roadISONEWAY: Boolean field indicating the presence of one way restrictionsISTOLL: Boolean field indicating the presence of a tollISFERRY: Boolean field to indicate whether the line segment represents a ferry routeISNOTROUTABLE: Boolean field used to designate line segments that should not be included in routing analysesFROMTODIRECTION: Used for routing analysesTOFROMDIRECTION: Used for routing analysesHIERARCHY: Used for routing analysesGlobalID: System-generated unique identifier for each record that is required in replicated geodatabasesFID_FROM_STREETNAME_TABLE: Unique identifier that can be joined to the FEATUREID field of the DOM_DIRECTION_TABLE to provide a link between the transportation line and the from street nameFID_TO_STREETNAME_TABLE: Unique identifier that can be joined to the FEATUREID field of the DOM_DIRECTION_TABLE to provide a link between the transportation line and the to street nameLIFECYCLESTATUS: Current state of the real-world featureLOCATION: Statement illustrating the whereabouts of a featureCOMFORTLEVEL: Comfort level of the path subtype only e.g. More ComfortableISPEDESTRIAN: Boolean field to indicate if there is pedestrian access present. Used for path and sidewalk subtypes onlyISBICYCLE: Boolean field to indicate whether the line segment represents a bicycle route. Used for path and sidewalk subtypes onlyISEQUESTRIAN: Boolean field to indicate whether the line segment represents an equestrian route. Used for path and sidewalk subtypes onlyWEBLINK: URL for a website related to the record SHAPE: System-generated geometry type of the featureSHAPE.len: System-generated length of the feature

Copyright Text: Created by the GIS Consortium's members with ongoing updates. Original information gathered from the county in which the road resides.

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 36000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:
Drawing Info: Advanced Query Capabilities:
HasZ: false

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: TYPE

Fields: Types:
Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
