Parent Layer: Water

Name: wsHydrant_POINT

Display Field: GEODBID

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: OBJECTID: System-generated unique identifier for each record within the feature classShape: System-generated geometry type of the feature GEODBID: Three-digit code that assigns editing responsibility to a community in the GIS ConsortiumFEATUREID: GIS-Consortium-generated unique identifier for each record within the feature class. All FEATUREIDs start with the GEODBID of the community that owns the record.DATECREATED: Date/time stamp from the moment the GIS record was createdDATEMODIFIED: Date/time stamp from the last moment the GIS record was changedSOURCE: Organization that provided the data. The GIS Consortium standard is to preface the source with the three-letter municipal code of the community providing the data, followed by a dash. Example: VGV-Public WorksSOURCETYPE: Accuracy context for the recordAncillaryRole: Attribute that indicates whether the junction pushes (source) or pulls (sink) flow in a geometric network. Default setting for the GIS Consortium is none.Enabled: Boolean field to indicate whether water is allowed to flow through this featureADMINISTRATIVEAREA: Owner of the area in which the feature is locatedINSTALLDATE: Date of installation for the real-world feature represented in the feature classLOCATIONDESCRIPTION: Statement illustrating the whereabouts of a featureOPERATIONALAREA: Retired field used to store a description for an operational area designated by a community ROTATION: Retired GIS tracking field used to turn the symbol that represents the feature on the map so that it matched how it would look in the real worldLIFECYCLESTATUS: Current state of the real-world featureSUBTYPE: Field's purpose is unknownWORKORDERID: Unique work order identifierELEVATION: Ground level height of real-world feature; measured in feet above sea levelWATERTYPE: Designation of water distribution or collection system to which the feature appliesBARRELDIAMETER: width of the barrel of the real-world feature; measured in inchesMAINVALVETYPE: Type of valve used for the hydrantNOZZLEDIAMETER1: The width measurement of one out of four possible nozzles on the hydrant; measured in inchesNOZZLEDIAMETER2: The width measurement of one out of four possible nozzles on the hydrant; measured in inchesNOZZLEDIAMETER3: The width measurement of one out of four possible nozzles on the hydrant; measured in inchesNOZZLEDIAMETER4: The width measurement of one out of four possible nozzles on the hydrant; measured in inchesOUTLETCONFIGURATION: The configuration of the hydrant outletsSEATDIAMETER: The width measurement of the hydrant seat; measured in inchesMANUFACTURER: company/organization that produces the real-world featureMODEL: Specific version of the manufactured real-world featureLEGACYTYPE: Retired GIS tracking code for the featureDEVICEID: Unique identifying code for the mechanical part, such as a serial number or model numberCOMMUNITYID: Unique identifying code selected by the communityOWNERSHIP: Organization with jurisdiction over the real-world feature represented in the feature classMAINTAINED: Organization responsible for the care of the real-world feature represented in the feature classDESCRIPTION: Statement illustrating the featureFID_SSJUNCTIONANNO_LINE: Unique identifier that can be joined to the FEATUREID field of the ssJunctionAnno_LINE feature class to provide a link between the feature and its label.CATEGORY: Retired field required for ArcGIS coverage modelsBREAKAWAYFLANGE: The description of the breakaway flange used within the fire hydrantDELINEATED: Field's purpose is unknownREPLICAFILTER: Code used to filter data for the creation of custom geodatabases PRODUCTIONNOTES: Technical notes from GIS personnelWEBLINK: URL for a website related to the recordDRAINER: Boolean field to indicate the presence of a drainerPURPOSE: Text field to describe how the hydrant is used, e.g. fire suppression, irrigationYard Hydrants– Typically used to provide water to an area in need of a water connection with no existing access. Used for washing, filling, and cleaning structures and equipment.Flushing Hydrant– typically used for flushinga water line of silt, rust, debris, or stagnant water. Typically only have one outlet and may be installed on dead-end lines.Irrigation Hydrant– typically used for agricultural applications including livestock and crops. Also used for turf grass watering. Fire Hydrant– Used for fire suppression purposes.GlobalID: System-generated unique identifier for each record that is required in replicated geodatabasesDATEPAINTED: The date of when the hydrant was last paintedHASFLAG: Indicates whether a hydrant has a flag or notCOLORSCHEME: Indicates the color of the asset

Copyright Text: Created by the GIS Consortium's members with ongoing updates.

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 100000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1014602.2410000004
YMin: 1770036.3484999985
XMax: 1169866.5007500015
YMax: 2103339.5247500017
Spatial Reference: 102671  (3435)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• GEODBID ( type: esriFieldTypeString, alias: GEODBID, length: 3 , Coded Values: [001: CHP] , [003: CPR] , [005: CDP] , ...81 more... )
• FEATUREID ( type: esriFieldTypeString, alias: FEATUREID, length: 15 )
• DATECREATED ( type: esriFieldTypeDate, alias: DATECREATED, length: 8 )
• DATEMODIFIED ( type: esriFieldTypeDate, alias: DATEMODIFIED, length: 8 )
• SOURCE ( type: esriFieldTypeString, alias: SOURCE, length: 20 )
• SOURCETYPE ( type: esriFieldTypeString, alias: SOURCETYPE, length: 20 , Coded Values: [ASBUILT: As-built] , [DATABASE: Database] , [ESTIMATED: Estimated] , ...12 more... )
• AncillaryRole ( type: esriFieldTypeSmallInteger, alias: AncillaryRole )
• Enabled ( type: esriFieldTypeSmallInteger, alias: Enabled , Coded Values: [0: False] , [1: True] )
• INSTALLDATE ( type: esriFieldTypeDate, alias: InstallDate, length: 8 )
• LOCATIONDESCRIPTION ( type: esriFieldTypeString, alias: LocationDescription, length: 200 )
• OPERATIONALAREA ( type: esriFieldTypeString, alias: OperationalArea, length: 20 )
• ROTATION ( type: esriFieldTypeDouble, alias: Rotation )
• LIFECYCLESTATUS ( type: esriFieldTypeString, alias: LifecycleStatus, length: 20 , Coded Values: [ABANDONED: Abandoned] , [ACTIVE: Active] , [PROPOSED: Proposed] , ...2 more... )
• SUBTYPE ( type: esriFieldTypeInteger, alias: Subtype )
• ELEVATION ( type: esriFieldTypeDouble, alias: Elevation )
• WATERTYPE ( type: esriFieldTypeString, alias: WaterType, length: 255 , Coded Values: [COMBINED: Combined Waste Water] , [EFFLUENT: Waste Water Effluent] , [POTABLE: Potable Water] , ...6 more... )
• BARRELDIAMETER ( type: esriFieldTypeDouble, alias: BarrelDiameter )
• MAINVALVETYPE ( type: esriFieldTypeString, alias: MainValveType, length: 20 )
• NOZZLEDIAMETER1 ( type: esriFieldTypeDouble, alias: NozzleDiameter1 )
• NOZZLEDIAMETER2 ( type: esriFieldTypeDouble, alias: NozzleDiameter2 )
• NOZZLEDIAMETER3 ( type: esriFieldTypeDouble, alias: NozzleDiameter3 )
• NOZZLEDIAMETER4 ( type: esriFieldTypeDouble, alias: NozzleDiameter4 )
• OUTLETCONFIGURATION ( type: esriFieldTypeString, alias: OutletConfiguration, length: 20 )
• SEATDIAMETER ( type: esriFieldTypeInteger, alias: SeatDiameter )
• MANUFACTURER ( type: esriFieldTypeString, alias: Manufacturer, length: 20 , Coded Values: [ADR: American Darling] , [AFD: American Foundry] , [APS: A.P.Smith] , ...31 more... )
• MODEL ( type: esriFieldTypeString, alias: MODEL, length: 30 )
• DEVICEID ( type: esriFieldTypeInteger, alias: DeviceID )
• COMMUNITYID ( type: esriFieldTypeString, alias: CommunityID, length: 20 )
• OWNERSHIP ( type: esriFieldTypeString, alias: Ownership, length: 9 , Coded Values: [COOK_CO: Cook County] , [IDOT: Illinois Department of Transportation] , [LAKE_CO: Lake County] , ...202 more... )
• MAINTAINED ( type: esriFieldTypeString, alias: Maintained, length: 9 , Coded Values: [COOK_CO: Cook County] , [IDOT: Illinois Department of Transportation] , [LAKE_CO: Lake County] , ...202 more... )
• DESCRIPTION ( type: esriFieldTypeString, alias: Description, length: 255 )
• FID_WSJUNCTIONANNO_LINE ( type: esriFieldTypeString, alias: FID_WSJUNCTIONANNO_LINE, length: 15 )
• BREAKAWAYFLANGE ( type: esriFieldTypeString, alias: BREAKAWAYFLANGE, length: 20 , Coded Values: [NO: No] , [YES: Yes] )
• DELINEATED ( type: esriFieldTypeString, alias: DELINEATED, length: 30 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• REPLICAFILTER ( type: esriFieldTypeString, alias: REPLICAFILTER, length: 255 )
• PRODUCTIONNOTES ( type: esriFieldTypeString, alias: PRODUCTIONNOTES, length: 100 )
• WEBLINK ( type: esriFieldTypeString, alias: WEBLINK, length: 255 )
• DRAINER ( type: esriFieldTypeSmallInteger, alias: DRAINER , Coded Values: [Yes: Yes] , [No: No] )
• PURPOSE ( type: esriFieldTypeString, alias: PURPOSE, length: 255 , Coded Values: [FIRE: Fire] , [FLUSHING: Flushing] , [IRRIGATION: Irrigation] , ...3 more... )
• HASFLAG ( type: esriFieldTypeSmallInteger, alias: HASFLAG , Coded Values: [Yes: Yes] , [No: No] )
• CREATEDBY ( type: esriFieldTypeString, alias: CREATEDBY, length: 100 )
• MODIFIEDBY ( type: esriFieldTypeString, alias: MODIFIEDBY, length: 100 )
• DATEABANDONED ( type: esriFieldTypeDate, alias: DATEABANDONED, length: 8 )
• OWNERSHIPDESCRIPTION ( type: esriFieldTypeString, alias: OWNERSHIPDESCRIPTION, length: 50 )
• MAINTAINEDDESCRIPTION ( type: esriFieldTypeString, alias: MAINTAINEDDESCRIPTION, length: 50 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• ESRIGNSS_ALTITUDE ( type: esriFieldTypeDouble, alias: Altitude )
• ESRIGNSS_LONGITUDE ( type: esriFieldTypeDouble, alias: Longitude )
• QANOTES ( type: esriFieldTypeString, alias: QA Notes, length: 255 )
• ESRIGNSS_AVG_V_RMS ( type: esriFieldTypeDouble, alias: Average Vertical Accuracy (m) )
• ESRIGNSS_V_RMS ( type: esriFieldTypeDouble, alias: Vertical Accuracy (m) )
• FIELDVERIFICATIONSTATUS ( type: esriFieldTypeString, alias: Field Verification Status, length: 10 , Coded Values: [CNL: Cannot Locate] , [CAN: Cannot Access] , [TODO: To Do] , ...2 more... )
• ESRIGNSS_LATITUDE ( type: esriFieldTypeDouble, alias: Latitude )
• ESRIGNSS_FIXTYPE ( type: esriFieldTypeSmallInteger, alias: Fix Type , Coded Values: [0: Fix not valid] , [1: GPS] , [2: Differential] , ...2 more... )
• ESRIGNSS_AVG_H_RMS ( type: esriFieldTypeDouble, alias: Average Horizontal Accuracy (m) )
• QASTATUS ( type: esriFieldTypeString, alias: QA Status, length: 10 , Coded Values: [RAW: Raw] , [CCN: Community Check Needed] , [COMPLETE: Complete] , ...1 more... )
• ESRIGNSS_H_RMS ( type: esriFieldTypeDouble, alias: Horizontal Accuracy (m) )
• FIELDVERIFICATIONNOTES ( type: esriFieldTypeString, alias: Field Verification Notes, length: 255 )
• DATESTAMPED ( type: esriFieldTypeDate, alias: DATESTAMPED, length: 8 )
• HASSECURITYDEVICE ( type: esriFieldTypeString, alias: HASSECURITYDEVICE, length: 10 , Coded Values: [NO: No] , [YES: Yes] )
• ISDEADEND ( type: esriFieldTypeString, alias: ISDEADEND, length: 10 , Coded Values: [NO: No] , [YES: Yes] )
• ESRIGNSS_POSITIONSOURCETYPE ( type: esriFieldTypeSmallInteger, alias: Position source type , Coded Values: [0: Unknown] , [1: User defined] , [2: Integrated (System) Location Provider] , ...3 more... )
• ESRIGNSS_RECEIVER ( type: esriFieldTypeString, alias: Receiver Name, length: 50 )
• ESRIGNSS_FIXDATETIME ( type: esriFieldTypeDate, alias: Fix Time, length: 8 )
• ESRIGNSS_CORRECTIONAGE ( type: esriFieldTypeDouble, alias: Correction Age )
• ESRIGNSS_STATIONID ( type: esriFieldTypeSmallInteger, alias: Station ID , Range: [0, 1023] )
• ESRIGNSS_NUMSATS ( type: esriFieldTypeSmallInteger, alias: Number of Satellites , Range: [0, 99] )
• ESRIGNSS_PDOP ( type: esriFieldTypeDouble, alias: PDOP )
• ESRIGNSS_HDOP ( type: esriFieldTypeDouble, alias: HDOP )
• ESRIGNSS_VDOP ( type: esriFieldTypeDouble, alias: VDOP )
• ESRIGNSS_DIRECTION ( type: esriFieldTypeDouble, alias: Direction of travel (°) )
• ESRIGNSS_SPEED ( type: esriFieldTypeDouble, alias: Speed (km/h) )
• ESRISNSR_AZIMUTH ( type: esriFieldTypeDouble, alias: Compass reading (°) )
• ESRIGNSS_AVG_POSITIONS ( type: esriFieldTypeSmallInteger, alias: Averaged Positions )
• ESRIGNSS_H_STDDEV ( type: esriFieldTypeDouble, alias: Standard Deviation (m) )
